2PCS Ultra small light DC 5V 1 channel DPDT Relay Module double Switch Board High level IO Control

Typical applications:

Product Name :2PCS Ultra small light DC 5V 1 channel DPDT Relay Module double Switch Board High level IO Control

Packing list:

2 PCS DR21B01 one Channel DC 5V DPDT Relay Module

Description:



DR21B01 5VDC one Channel DPDT Relay Board



Operating Voltage : DC 4.5-5.5V(5V)

Operating Current(Relay ON): 36MA

Standby Current(Relay OFF) : <1MA



Input control signal voltage:

                     0V - 0.6V Low stage (relay is OFF),

                     0.6V – 2.5V (unknown state).

                     2.5V - 24V High state (relay is ON).

Input control signal high state current:

                     2.5V: 0.15mA

                     5V: 0.4mA

                     12V: 1.2mA

                     20V: 2mA



Relay Load : 1A 125VAC;2A 30VDC





Size   : 22.86x18x14

Weight :6g







Schematic:
